OCI 3 Core Submersible Cable
Our 3 Core Submersible Cables are designed with high-purity 99.95% electrolytic copper conductors, offering superior current carrying capacity and minimal power loss. The insulation is made from a special PVC compound that provides excellent flexibility and water resistance, ensuring safe and reliable operation even under submerged conditions. The outer sheath is manufactured using a high-grade PVC compound, resistant to moisture, abrasion, oil, and grease, making it suitable for challenging environments. These cables are built to perform consistently under voltage fluctuations, delivering durability, safety, and efficiency.
Construction
- Conductor: Thin strands of high-purity (99.95%) electrolytic copper, multi-drawn for uniformity, flexibility, and low resistance.
- Insulation: Specially formulated super-flexible PVC compound with high water resistance properties.
- Sheathing: High abrasion-resistant PVC compound, impervious to water, oil, and grease.
- Core Arrangement: 3 cores laid in parallel position.
Technical Specification
| Voltage Rating |
Operating Temperature |
Bending Radius |
| 1100 V |
Max. 70˚C |
4 × overall diameter |
Applications
Widely used for irrigation pumps, drinking water supply systems, sewage treatment plants, firefighting equipment, and other submerged or damp environment applications.
Standards & Compliance
- Conductor: IS 8130
- Insulation & Sheathing: IS 5831
- General Compliance: IS 694:1990
Certifications & Standards
PVC 3 CORE FLAT CABLES FOR SUBMERSIBLE PUMPS (1100 VOLTS)
TABLE FOR SINGLE PHASE MOTOR MAXIMUM LENGTH OF COPPER CABLE
TABLE FOR SINGLE PHASE MOTOR MAXIMUM LENGTH OF COPPER CABLE
CABLE SELECTION CHART AT 30° C 415V (WITH DOL STARTER)
CABLE SELECTION CHART AT 30° C 415V (WITH STAR DELTA STARTER DOUBLE CABLE)
CABLE SELECTION CHART AT 30° C 415V (WITH STAR DELTA STARTER DOUBLE CABLE)
