OCI Jelly Filled Co-Axial Cable
OCI Jelly Flooded Co-Axial Cables are designed to provide smooth and reliable signal transmission for CATV networks. Manufactured in India with precision, these cables combine superior electrical performance with durability, ensuring consistent results in both indoor and outdoor installations.
Construction
- RG-59 F / RG-6 F / RG-11 F: Solid bare copper conductor
- RG-6 CCS / RG-11 CCS: Solid copper-clad steel conductor
- Insulation: Foam HDPE (High Density Polyethylene) with nitrogen gas injection
- Inner Shielding: Bonded aluminium foil
- Braiding: Aluminium alloy wire (60% coverage)
- Jelly flooded core for moisture protection
- Outer Sheath: Flame retardant PVC, Black in colour
Technical Specification
| Operating Temperature |
Bending Radius |
| Max 70°C |
20 × Overall Diameter |
Applications
OCI Co-Axial Cables are suitable for CATV networks requiring high-frequency and broadband signal transmission. They are ideal for low-power video signals and can be used in both external and internal installations
Standards & Compliance
- ANSI/SCTE 74 – 2011
- Armoured options available on request
Certifications & Standards
ELECTRICAL CHARACTERISTICS
