Armoured Lan Cable
OCI CAT 6 UTP Cables
OCI CAT 6 Outdoor Cables are designed for demanding environments where durability and performance must go hand in hand. With a rugged double-jacket construction, these cables deliver reliable high-speed data, voice, and video transmission across LANs. Engineered to support Gigabit Ethernet (1000 Base-T) standards and operate at bandwidths up to 250 MHz, OCI Outdoor CAT 6 cables are the ideal choice for long-lasting performance in above-ground and external installations.
Construction
- Conductor: 23 AWG solid bare copper
- Insulation: High-density polyethylene (HDPE)
- Separator: PE cross separator for signal integrity
- Inner Sheath: PVC layer for insulation stability
- Outer Jacket: Rugged black HDPE / LSZH / Anti-rodent protection
- Rip Cord: Nylon for easy jacket removal
- Pairs:4 solid twisted pairs
Technical Specification
| Mechanical Properties |
Electrical Properties |
- Cable diameter: 7.5 ± 0.5 mm
- Minimum bending radius: 8 × OD at 20°C
- Pulling force: Up to 25 lbs
- Installation temperature: 0°C to +50°C
- Operating temperature: -20°C to +60°C
|
- Operating voltage: 72 V
- Conductor resistance: Max 9.2 Ω / 100 m
- Resistance unbalance: ≤ 5%
- Mutual capacitance: 5.6 nF / 100 m
- Capacitance unbalance: 330 pF / 100 m
- Delay skew: ≤ 48 ns / 100 m
- Propagation delay: < 538 ns / 100 m
- Nominal velocity of propagation (NVP): 69%
- Dielectric strength: 1000 V RMS
- Insulation resistance: 100 MΩ
- Current rating: Max 1.5 A
|
Applications
- High-performance LAN cabling for residential, commercial, and industrial networks
- Data centers and backbone installations
- Transmission of voice, video (RGB), and digital signals
- Outdoor applications requiring extra protection against environmental stress
Standards & Compliance
- ANSI/TIA-568-C.2
- ISO/IEC 11801
