OCI CAT 6E Cables

OCI CAT 6E UTP Cables are designed to meet the ever-growing demands of modern high-speed data networks. With advanced engineering and high-grade materials, these four-pair, 100-ohm impedance cables ensure reliable signal transmission across extended distances of up to 100 meters—without the need for amplifiers. Ideal for data, voice, and video transmission, OCI CAT 6E cables support a wide range of applications including ISDN, Fast and Gigabit Ethernet, ATM up to 622 Mbps, 1000 BASE-T, 10Gb Ethernet, and future-ready protocols.

LAN CABNLE

Construction

  • Conductor: 23 AWG solid bare copper
  • Insulation: High-density polyethylene (HDPE)
  • Separator: Polyethylene (PE) cross separator for pair isolation
  • Jacket: Flame-retardant (FR) PVC sheath, light grey (custom colours available)
  • Rip Cord: Nylon for easy stripping
  • Pairs: 4 solid twisted pairs

Technical Specification

Mechanical Properties Electrical Properties
  • Installation temperature: 0°C to +50°C
  • Operating temperature: -20°C to +60°C
  • Pulling force: Up to 25 lbs
  • Cable diameter: 6.6 ± 1.0 mm
  • Minimum bending radius: 4 × OD at 20°C
  • Conductor resistance: Max 9.2 Ω / 100 m
  • Resistance unbalance: ≤ 5%
  • Mutual capacitance: 5.6 nF / 100 m
  • Capacitance unbalance: 330 pF / 100 m
  • Nominal velocity of propagation (NVP): 69%
  • Insulation resistance: 100 MΩ
  • Dielectric strength: 1000 V RMS
  • Operating voltage: 72 V
  • Delay skew: ≤ 48 ns / 100 m
  • Propagation delay: < 542 ns / 100 m
  • Current rating: Max 1.5 A

Applications

  • Local Area Network (LAN) cabling for residential, commercial, and industrial infrastructure
  • High-performance data centers and enterprise networks
  • High-speed transmission of voice, video, and data
  • Backbone cabling for modern IT and communication systems

Standards & Compliance

  • ANSI/TIA 568-C.2 Cat 6A
  • ISO/IEC 11801 EA
