OCI Rubber Cable
OCI Rubber Cables are designed to deliver reliable performance in challenging environments where durability, flexibility, and safety are critical. Manufactured with high-quality tinned copper conductors, elastomeric insulation, and HOFR sheathing, these cables are built to withstand mechanical stress, high temperatures, and harsh industrial conditions. They are ideal for elevators, cranes, mining operations, heating equipment, and other demanding applications.
Construction
- Conductor: Annealed tinned electrolytic grade copper (Class 5 as per IS 8130)
- Insulation: Elastomeric compound IE 2 (EPR) as per IS 6380
- Sheath: HOFR (Heat and Oil Resistant, Flame Retardant) elastomer sheath as per IS 6380
Technical Specification
| Voltage Rating |
Operating Temperature |
Maximum Short-Circuit Temperature |
Test Voltage |
Bending Radius |
Fixed Installation |
Occasional Movement |
| 1100 V (AC), up to 1500 V (DC to earth) |
-40°C to +90°C |
250°C |
3000 V AC |
- |
12 × OD |
10 × OD |
Applications
- Elevators, lifts, and cranes
- Mining and heavy industrial machinery
- Heater leads and electrical irons
- Environments requiring flexibility and resistance to heat, oil, and mechanical stress
Standards & Compliance
- IS 8130:2013
- IS 6380:1984
- IS 9968:1988
- Flammability Test: IEC 60332-1-2
- Tested for conductor resistance, covering resistance, and durability
Certifications & Standards
OCI RUBBER CABLES, 1100 V AC
( SIZE AND DIMENSIONS AND RATINGS
