XLPE Armoured & Unarmoured Cable

OCI Low Tension (LT) cables with XLPE (Cross-Linked Polyethylene) insulation are crafted for reliable power transmission and distribution up to 1.1 kV. Designed to meet the demands of residential, commercial, and industrial sectors, these cables combine strength, safety, and durability. The advanced XLPE insulation provides superior thermal stability, electrical performance, and resistance to harsh environments, making OCI cables a trusted choice for modern infrastructure.

Construction

Conductor:
  • High conductivity annealed copper or aluminum conductor
  • Solid, stranded, or flexible construction
  • As per IS 8130 / IEC 60228 (Class 1/2/5)
Insulation:
  • XLPE (Cross-Linked Polyethylene) insulation
  • Provides excellent electrical and thermal performance
  • Colour coded for easy identification
Inner Sheath (for multi-core cables):
  • Extruded PVC or LSZH compound
  • Ensures smooth bedding over insulated conductors
Armour (optional):
  • Galvanized Steel Strip (for smaller sizes) or
  • Galvanized Steel Wire (for larger sizes)
  • Provides mechanical protection for underground or outdoor applications
Outer Sheath:
  • PVC / HDPE / LSZH compound
  • Resistant to abrasion, moisture, oils, and chemicals
  • Black as standard, other colors on request

Technical Specification

Voltage Rating Conductor Insulation Operating Temperature Short-Circuit Temperature Outer Sheath Armour
Up to 1.1 kV Copper or Aluminium XLPE -40°C to +90°C 250°C (5 sec max) PVC, HDPE, or LSZH Armoured or Unarmored

Applications

  • Residential, commercial, and industrial wiring
  • Power distribution and transmission networks
  • Control panels, machinery, and equipment wiring
  • Underground cabling with armoured protection
  • Outdoor installations exposed to weather and stress

Standards & Compliance

  • IS 1554 (Part 1)
  • IS 8130 (Conductors)
  • IEC 60502-1
  • Compliance with flame retardant and insulation resistance requirements
